20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance

China 20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance supplier

Large Image :  20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance

Product Details:

Place of Origin: CHINA
Brand Name: GUANGMING
Certification: ISO9001
Model Number: GMS

Payment & Shipping Terms:

Minimum Order Quantity: 10SM
Price: USD4 per SM
Packaging Details: wooden box , OR as your request
Payment Terms: Western Union
Supply Ability: 2000SM PER DAY
Contact Now
Detailed Product Description
Mesh Material: SS304 Or 316 Mesh Layer: 2 Or 3
Micron: 1-500 Standard Length: 30m
Application: Filters Wire Diameter: 0.0203-1.80mm



High corrosion resistance 20-325 micron stainless steel filter wire mesh










material

common material:stainelss steel 304 316 904L 2205 2207 430 310 317 309 etc.

304L 316L

  special material:pure nickel wire, Ni-cr wire, monel, inconel wire etc.
wire diameter 0.023-2.8mm
weaving type

plain weave, twill weave and dutch weave, bamboo weave

Hollander weave etc.

mesh counts 1-2300meshes
micron size 500 400 300 200 100 80 70 25 micron
technique woven wire mesh
mesh rolls size 1x30m 2x30m 1.524x30m 0.914x30m etc.
sample free and avaliable
surface flat and bright



Feature of the stainless steel wire mesh

  • Corrosion resistance.
  • Anti-acid and alkali resistance
  • Anti-high temperture.
  • Good filter performance.
  • Long using life

Application of the stainelss steel wire mesh

  • In acid, alkali environment conditions sieving and filtering.
  • Petroleum industry as mud mesh,.
  • Chemical fiber industry as screen mesh.
  • Plating industry as acid cleaning mesh.

20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance  20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance



20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance  20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance



Stainless Steel Wire Mesh
Mesh/Inch Diameter
(mm)
Aperture
(mm)
2MESH 1.8 10.90
3MESH 1.6 6.866
4MESH 1.2 5.15
5MESH 0.91 4.17
6MESH 0.80 3.433
8MESH 0.60 2.575
10MESH 0.55 1.990
12MESH 0.50 1.616
14MESH 0.45 1.362
16MESH 0.40 1.188
18MESH 0.35 1.061
20MESH 0.30 0.970
26MESH 0.28 0.696
30MESH 0.25 0.597
40MESH 0.21 0.425
50MESH 0.19 0.318
60MESH 0.15 0.273
70MESH 0.14 0.223
80MESH 0.12 0.198
90MESH 0.11 0.172
100MESH 0.10 0.154
120MESH 0.08 0.132
140MESH 0.07 0.111
150MESH 0.06 0.109
160MESH 0.06 0.099
180MESH 0.053 0.088
200MESH 0.053 0.074
250MESH 0.04 0.062
300MESH 0.035 0.050
325MESH 0.03 0.048
350MESH 0.03 0.043
400MESH 0.025 0.0385
500MESH 0.025 0.0258
635MESH 0.020 0.020
Width 0.4m-8m



20-325 Micron Stainless Steel Filter Wire Mesh High Corrosion Resistance



GUANGMING METAL PRODUCTS CO., LTD strives for the existence by qualiy,for development by reputation. Our company has high quality products,best prices and reliable after -sale services. On the basis of mutually beneficial and friendly cooperation. We really hope to establish good business relationship and create a better future with old and new customers at home and abroad .
